BAOFENG UV-9R PLUS

BAOFENG UV-9R PLUS
Category:

BAOFENG UV-9R PLUS

Price : INR 4000 to 6500 Per Piece

Range : 2 to 6 Kms in City & Upto 15 Kms in Open Area

₹4,500.00

Description

  • 1 x Baofeng BF-UV9R Plus Radio
  • 1 x Antenna
  • 1 x Li-ion battery pack
  • 1 x Belt clip
  • 1 x The sling
  • 1 x Power Charger
  • 1 x User manual
General
Frequency Rangee VHF:136-174MHz UHF400-520MHz
Channel Capacity 128
Channel Spacing 25KHz/12.5KHz
Antenna Impedance 50Ω
Microphone Impedance 600Ω
Operating Voltage 7.4V DC±15%
Frequency Stability ±2.5ppm
Battery 4500mAh (Polymer Li-ion)
Compatible With American Military Standard(Mil-STD-810C/D/E)
Transmitter(EIA-RS 316B STANDARD)
RF Power Output 15W
Modulation Type FM Radio (65.0MHz-108.0MHz)
Modulation Sensitivity <15µV
Modulation Distortion ≤3%
Max Freq Deviation <5KHz
Occupied Bandwidth ≤16KHz
Modulation Feature ±3dB
Spurious Radiation ≤7.5μW
Adjacent Channel Power ≤-65dB
Receiver
Sensitivity(12db SINAD) ≤0.15μ(12dB S/N)
Squelch Sensitivity ≤0.1μV
Audio Power output 1W/16Ω
Audio Respond -6
Operation Bandwidth >5KHz
Co-channel Rejection ≥-8dB
Blocking ≥85dB
Adjacent Channel Selectivity ≥65dB
Standby Current 60mA,15mA
Spurious Rejection ≥60dB
Intermodulation Resistance ≥60dB
  • IP68 waterproof and dustproof (Not diving)
  • Relay Forwarding Confirmed (1750 HZ)
  • Dual Band, Dual Display and Dual Standby
  • High &Low Power Switchover
  • Battery Saving
  • V0X Function
  • Wide/Narrow Band Selection
  • Auto-Back Light
  • Dual Band Standby
  • Time-out Timer (TOT)
  • 50 CTCSS and 104 DCS Codes
  • Voice Prompt
  • ANI Code
  • PC or Manual Program
  • DTMF Code
  • PTT-ID
  • ATUO Keypad Lock
  • Busy Channel Lock Function
  • Low Battery Warning
  • Emergency Alarm
  • Priory Scanning Function
  • U/V Cross Band Dual Watch
  •

Disclosure : Apart from ETA approved License free Walkie Talkies which are prescribed in details by Gazette Notification number REGD. NO. D. L-33004/99 Dated 18 October 2018, to buy any other walkie talkie please apply and get a valid Wireless Operating License (WOL) which is issued by Department of Telecom, Government of India under Indian Telegraph Act 1885.
